Soundcraft Ui24R 24-Ch Digital Mixer & USB Multi-Track Recorder (Each)
Ask us about an exclusive price for Soundcraft Ui24R 24-Ch Digital Mixer & USB Multi-Track Recorder (Each)
Click Here for Discount Price
Genuine Product
100% Original
Authentic products sourced through authorized and verified channels. We never sell refurbished, used or parallel imported items.
Brand New & Sealed
Factory Sealed Item
Brand new, unused and factory sealed for complete peace of mind.
Manufacturer Warranty
Official Warranty
Official manufacturer warranty for your complete protection.
GST Invoice Included
Proper GST Invoice
Receive a valid GST invoice with every purchase.
Cash on Delivery
COD Available
Cash on Delivery is available for eligible products and locations.
Secure Payment
Safe & Secure Checkout
Your payment information is always safe and encrypted.
Expert AV Support
Professional Assistance
Get expert help before and after your purchase.
Fast & Secure Delivery
Delivery in 3–6 Days
Delivery in 3–6 days with secure and safe packaging. Subject to our shipping policy.
7 Days Return Policy
7-Day Returns
Returns are available within 7 days, subject to our return policy.
Couldn't load pickup availability
Description
Soundcraft Ui24R 24-Channel Digital Mixer and USB Multi-Track Recorder Delivering Remote Wireless Control from Any Device, 32-In/32-Out USB Recording, Built-In Lexicon and dbx Processing, and Comprehensive I/O in a Compact Rack-Mount Chassis
The Soundcraft Ui24R is a rack-mountable 24-channel digital mixing console and 32-in/32-out USB multi-track recorder that brings professional-grade digital mixing, built-in Harman signal processing, and full wireless remote control via any iOS, Android, Windows, or Mac device to live sound, installed AV, and studio recording environments. With 20 remote-controllable mic preamp inputs, four stereo line inputs, built-in Lexicon reverb and delay effects, dbx DriveRack-derived speaker processing, and the ability to record every input simultaneously to a connected USB drive or computer, the Ui24R is uniquely suited for live recording rigs, houses of worship, corporate AV installations, and touring engineers who need maximum capability in a minimal footprint.
Key Features
- Wireless Remote Control — Full mixing control from any iOS, Android, Windows, or Mac device via built-in Wi-Fi router — no dedicated computer or tablet required; control from front-of-house, stage, or anywhere in the venue
- 24 Channels with 20 Remote-Controllable Mic Preamps — 20 XLR mic inputs with remote-controllable gain via the wireless interface, plus four stereo line inputs for a total of 24 mix channels
- 32-In/32-Out USB Multi-Track Recording — Record all 32 channels simultaneously to a USB storage device or computer for virtual soundcheck, live album recording, or post-production mixing
- Built-In Lexicon Effects — Eight channels of Lexicon reverb and delay effects with independent processing per channel for polished live and studio-quality spatial effects
- dbx DriveRack Speaker Processing — Built-in dbx-derived speaker management including RTA, parametric EQ, crossover, limiting, and delay for precise PA system control
- 4-Band Parametric EQ & Gate/Compressor per Channel — Full dynamics and EQ processing on every input channel for professional mix control
- 10 Mix Outputs — Main LR + 8 configurable aux/monitor mix outputs for comprehensive stage monitoring and zone routing
- Rack-Mount Chassis — 2U rack-mountable form factor for permanent AV rack installation or touring rack use
Specifications
| Specification | Details |
|---|---|
| Input Channels | 24 (20 × XLR mic + 4 × stereo line) |
| Mic Preamps | 20 (remote-controllable gain via wireless interface) |
| Phantom Power | Yes (+48V, per channel) |
| EQ | 4-band parametric EQ per channel |
| Dynamics | Gate + Compressor per input channel |
| Effects | 8 × Lexicon reverb/delay engines |
| Speaker Processing | dbx DriveRack-derived (RTA, PEQ, crossover, limiter, delay) |
| Mix Outputs | Main LR + 8 aux/monitor outputs (10 total) |
| USB Recording | 32-in/32-out multi-track USB recording (to USB drive or computer) |
| Wireless Control | Built-in Wi-Fi router; iOS, Android, Windows, Mac compatible |
| Main Outputs | 2 × XLR (balanced) |
| Aux Outputs | 8 × XLR (balanced) |
| Rack Size | 2U rack-mountable |
| Dimensions (H × W × D) | 88 × 482 × 370mm (2U) |
| Weight | Approx. 6.8kg |
| Finish | Black |
What's in the Box
- 1 × Soundcraft Ui24R Digital Mixer
- Rack-mount ears
- IEC power cable
- User manual
