Yamaha MG16XU 16-Ch Analogue Mixer with USB & SPX Effects (Each)
Genuine Product
100% Original
Authentic products sourced through authorized and verified channels. We never sell refurbished, used or parallel imported items.
Brand New & Sealed
Factory Sealed Item
Brand new, unused and factory sealed for complete peace of mind.
Manufacturer Warranty
Official Warranty
Official manufacturer warranty for your complete protection.
GST Invoice Included
Proper GST Invoice
Receive a valid GST invoice with every purchase.
Cash on Delivery
COD Available
Cash on Delivery is available for eligible products and locations.
Secure Payment
Safe & Secure Checkout
Your payment information is always safe and encrypted.
Expert AV Support
Professional Assistance
Get expert help before and after your purchase.
Fast & Secure Delivery
Carefully Packed & Shipped
Quick delivery with secure and premium packaging.
Couldn't load pickup availability
Yamaha MG16XU 16-Channel Analogue Mixing Console with USB Audio Interface and SPX Effects Delivering Ten D-PRE Discrete Class-A Microphone Preamps, Plug-and-Play USB Recording, and Studio-Quality Built-In Effects for Live Sound, Houses of Worship, and Medium Venue Installations
The Yamaha MG16XU builds on the MG16 with the addition of a stereo USB audio interface for driverless computer recording and playback, a 24-program SPX multi-effects processor, and per-channel 1-knob compressors on all ten mono mic inputs — making it a comprehensive all-in-one mixing solution for live bands, rehearsal rooms, houses of worship, and medium venue installations who need professional D-PRE preamp quality, USB recording capability, built-in SPX effects, and dynamics processing in a single, robust analogue console. The class-compliant USB interface works with all major DAWs on Mac and PC without driver installation, while the four group buses provide flexible sub-mixing and recording routing for larger productions.
Key Features
- Yamaha D-PRE Discrete Class-A Mic Preamps — Ten channels of D-PRE discrete class-A microphone preamps delivering ultra-low noise, wide dynamic range, and transparent Yamaha preamp character
- Stereo USB Audio Interface — Class-compliant stereo USB send/return for plug-and-play DAW recording and computer playback on Mac and PC without drivers
- 24-Program SPX Multi-Effects Processor — Built-in SPX effects with 24 programs including reverb, chorus, flanger, phaser, delay, and combination effects
- 1-Knob Compressor on Mic Channels — Per-channel single-knob compressor on all ten mono mic inputs for easy dynamic control on vocals and instruments
- 4 Group Buses — Four assignable group buses for sub-mixing, VCA-style grouping, and multitrack recording routing
- +48V Phantom Power — Switchable phantom power for condenser microphones on all XLR inputs
- 3-Band EQ with Swept Mid on Mono Channels — High shelf, continuously sweepable mid (100Hz–8kHz), and low shelf EQ on all mono channels for precise tonal control
- 2 Aux Sends per Channel — Two auxiliary sends per channel for monitor mixes and effects routing
- Balanced XLR Main Outputs — Professional balanced XLR main outputs for PA amplifiers or powered speakers
Specifications
| Specification | Details |
|---|---|
| Channels | 16 (10 mono XLR/TRS combo + 3 stereo line) |
| Mic Preamps | 10 × Yamaha D-PRE discrete class-A |
| Phantom Power | Yes (+48V, switchable) |
| Compressor | 1-knob compressor on mono mic channels |
| Effects | SPX multi-effects processor, 24 programs (reverb, chorus, flanger, phaser, delay, and more) |
| USB | Stereo USB audio interface (send/return, class-compliant, driverless) |
| EQ (Mono) | 3-band: High shelf, Swept Mid (100Hz–8kHz), Low shelf |
| EQ (Stereo) | 2-band: High shelf, Low shelf |
| Group Buses | 4 |
| Aux Sends | 2 per channel |
| Main Outputs | 2 × XLR (balanced) + 2 × TRS (balanced) |
| Group Outputs | 4 × TRS (balanced) |
| Monitor Output | 1 × Stereo TRS |
| Headphone Output | 1 × 6.35mm TRS with level control |
| Power | External PSU (included) |
| Dimensions (H × W × D) | 107 × 480 × 356mm |
| Weight | Approx. 6.2kg |
| Finish | Black |
What's in the Box
- 1 × Yamaha MG16XU Analogue Mixing Console
- USB cable
- External power supply
- User manual
Ideal for live bands, houses of worship, corporate AV, and medium venue installations. Pair with active PA speakers and stage monitors for a complete professional live sound and recording setup. Available at Harmony AV — Authorized Yamaha Professional Dealer in India.
